Axiom Elite CNC – AR8 Elite (24″ x 48″)
15
People watching this product now!
-
Warranty 1 year
-
Free 30-Day returns
付款方式：
Description
Axiom Elite Series
AR8 ELITE (24″” x 48″”)
?Servo Driven Performance
?Unparalleled Speed & Precision
?3HP ER-20 Electro Spindle
?On-Board Liquid Cooling System
?Precision Ball Screws
?Prismatic Guides in all Axes
?Industrial 4-Axis CNC Controller
?Stand and Tool Storage Included
The Axiom Precision AutoRoute Elite CNC router represents the most advanced technology that is primarily found on machines in industrial shops. They offer the speed. torque and precision which can only be found in servo-driven machines. Cut at up to 320 IPM while maintaining repeatability of .05mm!
Our Elite Series CNC routers have a full 8” Z travel capacity. and a quiet yet powerful 3HP electro-spindle with integrated liquid cooling system. All Elite Series routers utilize 20mm precision ball screws. massive prismatic guides. a robust steel frame. and interlocking aluminum table. In addition. the integrated MDF spoil boards promise you the all precision you need. since they can easily be milled flat for a true perpendicular surface to the spindle.
There is no need to attach your CNC router to your computer to operate it. Simply transfer your file to the controller via USB storage device. The hand-held RichAuto B58 DSP controller is powerful. easy to use. and 4th-axis ready.
**Note: This item does not qualify for free shipping. Shipping will be billed separately. Please contact us for an estimate.**
** Lead time 7-10 business days
X Axis Travel |
24 ?(610mm) |
Y Axis Travel |
48″” (1210mm) |
Z Axis Travel |
7.48 ?(190mm) |
Table Work Area |
28.4”W x 63”L |
Spindle Configuration |
ER20 |
Included Collets |
1/4″” & 1/2″” |
Electro Spindle |
2.2KW (3HP) |
Spindle Speed |
0~24000 RPM |
Rapid Feed Rate |
320 IPM (8 MPM) |
Precision Linear Guideway |
X/Y/Z |
Precision Ball Screw |
X/Y/Z |
Ball Screw Diameter |
X=20mm . Y=25mm . Z=16mm |
Positional Accuracy |
+/-.00197 ?(0.05mm) |
Power Requirements |
10A (AR8)/15A (AR16). 220V. 1PH. 50~60Hz |
Working Table |
High rigidity Aluminum Extrusion |
Gantry Bridge |
High rigidity Aluminum Extrusion |
Gantry Supports |
Aluminum alloy gravity cast |
Max Gantry Clearance |
9.25″” (234.95mm) |
Gantry Clearance Above Spoil Brds |
8.25″” (209.55mm) |
Machine Base |
All Welded Steel Frame |
Machine Shipping Dimensions |
66″”L x 40″”W x 47″”H |
Machine Shipping Weight |
764 lbs |
Tool Touch-Off Device |
Included |
Onboard Cooling |
System Included |
Controller |
RichAuto B58 Industrial 4-Axis CNC ControllerDSP CNC motion control systemUSB port for easy file transfer |
Language |
Support English / Chinese |
