Bambu Lab X1E 3D Printer

Bambu Lab X1E

For professionals and engineering applications

Available and ready to ship today!

Request A Quote
or call (813) 280-1115

Enhanced and More Connection Options

Stable Ethernet Connection. WPA2-Enterprise Authentication Wi-Fi Connection

The X1E offers the option to connect to your devices through its newly added Ethernet port. ensuring robust network communication in complex environments. Ethernet connectivity can also be used in crowded wireless signal environments. Additionally. the X1E provides WPA2-Enterprise Wi-Fi Authentication (EAP-PEAP/EAP-TLS/TAP-TTLS) and individual physical kill switches for both Wi-Fi and Ethernet. meeting stringent network security requirements.

Off-Cloud Operation

Fully Functional With LAN Only Mode

The X1E can operate independently without a connection to Bambu Cloud Service. fully functional within your local network. Customers can remotely control the X1E through LAN communication without requiring an Internet connection. For additional customization details. please contact your regional reseller.

Heavy Duty Air Filtration

Effectively Filter Particulates And VOCs Generated by 3D Printing

We combined a G3 pre-filter. an H12 HEPA filter. and a high-quality coconut shell activated carbon filter to provide optimal air filtration. Enhanced filtration can effectively reduce excessive odors and particulates when printing in less ventilated environments.

Active Heating And Controlled Chamber Temp

Reduce Warping. Improve Layer Bonding

The X1E can actively heat and regulate the chamber temperature. Accurately controlled chamber temperature (up to 60 C or 140 F) improves print quality. especially for filaments prone to warping such as ABS and PC.

320 C (608 F) Nozzle Temp

More Heat For Higher Temperature Materials

Higher nozzle temperature make possible to print higher performance materials such as PPA-CF/GF. PPS and PPS-CF. These new materials have better dimensional stability. heat resistance and mechanical performance.

Robust High Speed CoreXY

Super Fast And Rigid Structure For Continuous High Speed Printing

The superior carbon-fiber rods in the CoreXY motion structure enable the X1E to achieve a toolhead acceleration of 20.000 mm/s2 by reducing the weight of moving parts. This faster acceleration allows the X1E to maintain its maximum travel speed of 500 mm/s for longer periods. significantly reducing overall print time.

Vibration And Extrusion Compensation

Stable & Quality Prints Even At Higher Speeds

X1E can actively compensate for XY-axis vibrations and extrusion issues to ensure exceptionally smooth print quality. All measurements are fully automatic. eliminating the need for manual adjustments.

AI Failure Detection

Reduce Filament Wastage And Machine Downtime

The X1E’s AI algorithm can detect first-layer imperfections and spaghetti failures with the assistance of Lidar and computer vision. It then automatically pauses the print to prevent catastrophic failures.

Intelligent Filament Management

Supports Auto Filament Reload and Enables Multi-Material Printing with Support Material for Improved Surface Quality

X1E can parallel connect 4 Bambu AMS systems to print with up to 16 spools of filaments. good for printing dedicated support materials for seamless surface and printing multi-color. The AMS system also supports automatic filaments reload. to used up all filament on one spool before switching to the next.

X1E

Wi-Fi
Frequencey Range: 2400 MHz – 2483.5 MHz

WPA2-Enterprise:
EAP-PEAP
EAP-TLS
TAP-TTLS

Ehternet
Socket: RJ45
Speed: 100 Mbps / Full Duplex

Supported Filaments
PLA. PETG. TPU. PVA. BVOH: Optimal
ABS. ASA. PC. PA. PET: Superior
Carbon/Glass Fiber Reinforced PLA. PETG. PA. PET. PC. ABS. ASA: Superior
PPA-CF/GF. PPS. PPS-CF/GF: Ideal

Heating
Active Chamber Heating: Yes
Maximum Chamber Control Temperature: 60

Air Purification
Pre-filter grade: G3
HEPA filter grade: H12
Activated Carbon Filter type: Coconut Shell Granulated
VOC Filtration: Optimal
Particulate Matter Filtration: Yes

Network Control
Ethernet: Yes
Wireless Network: Wi-Fi
Network Kill Switch: Wi-Fi & Ethernet
Removable Network Module: Yes
802.1X Network Access Control: Yes

Toolhead
Hot End: All-Metal
Nozzle: Hardened Steel
Max Hot End Temperature: 320

Heatbed
Build Plate: Flexible Steel Plate
Build Plate Surface (Included): Bambu Textured PEI Plate
Max Build Plate Temperature: 110 @220V . 120 @110V

Speed
Max Speed of Toolhead: 500 mm/s
Max Acceleration of Toolhead: 20000 mm/s2

Sensors
Bambu Micro Lidar: Yes
Chamber Monitoring Camera: 1920*1080 Included

Physical Dimensions
Dimensions: 389*389*457 mm3
Net Weight: 16kg

X1-Carbon

Wi-Fi
Frequencey Range: 2400 MHz – 2483.5 MHz

WPA2-Enterprise:
No

Ethernet
Socket: /
Speed: /

Supported Filaments
PLA. PETG. TPU. PVA. BVOH: Optimal
ABS. ASA. PC. PA. PET: Ideal
Carbon/Glass Fiber Reinforced PLA. PETG. PA. PET. PC. ABS. ASA: Ideal
PPA-CF/GF. PPS. PPS-CF/GF: No

Heating
Active Chamber Heating: No
Maximum Chamber Control Temperature: /

Air Purification
Pre-filter grade: None
HEPA filter grade: None
Activated Carbon Filter type: Coal Based Pellets
VOC Filtration: Capable
Particulate Matter Filtration: No

Network Control
Ethernet: No
Wireless Network: Wi-Fi
Network Kill Switch: No
Removable Network Module: No
802.1X Network Access Control: No

Toolhead
Hot End: All-Metal
Nozzle: Hardened Steel
Max Hot End Temperature: 300

Heatbed
Build Plate: Flexible Steel Plate
Build Plate Surface (Included): Bambu Cool Plate. Bambu Engineering Plate
Max Build Plate Temperature: 110 @220V . 120 @110V

Speed
Max Speed of Toolhead: 500 mm/s
Max Acceleration of Toolhead: 20000 mm/s2

Sensors
Bambu Micro Lidar: Yes
Chamber Monitoring Camera: 1920*1080 Included

Physical Dimensions
Dimensions: 389*389*457 mm3
Net Weight: 14.13kg
