Ultimaker PVA Removal Station
Simple post-processing. Faster parts
Note: Limited Stock. Will ship immediately.
Make printing complex designs faster and easier. The Ultimaker PVA Removal Station dissolves support material quickly and effectively. keeping operator time to a minimum and increasing productivity.
Rapid prototyping just got faster. And easier
Dissolves PVA up to 4x faster
Less post-processing operator time
Use with Ultimaker or 3rd-party PVA
Just add water. No chemicals. no mess
Remove PVA up to 4x faster
Shrink your post-processing time
High-speed water circulation driven by a magnetic rotor removes PVA up to four times faster than motionless water. even from hard-to-reach cavities. So you have your parts post-processed and ready to use as soon as possible.
Low effort. higher productivity
Reduce operator time up to 80%1
The Ultimaker PVA Removal Station requires only a few minutes of operator time per print. with minimal maintenance needs. Just press the start button. leave it to do its job. and collect your print when it’s ready.
Key features
Rotor-powered water circulation
Choose 100 or 225 RPM circulation depending on the fragility of your part. Every two minutes. the rotor changes direction to push water evenly against the model.
Prints stay safe and submerged
A rinsing basket keeps your print in place and completely submerged while dissolving. then lifts up for mess-free draining and print removal.
Easy to monitor progress
A transparent. illuminated container lets you easily follow the PVA removal process and see when your part is ready. Plus. a saturation indicator shows when to refresh the water.
Your design-to-print workflow. simplified
Fill
Fill the container with tap water. place it back on the docking station. and place your 3D print inside.
Fill
Fill the container with tap water. place it back on the docking station. and place your 3D print inside.
Dissolve
Start the PVA removal process with the touch of a button. Let the PVA dissolve. typically within 1-8 hours2. while you get on with your day
Dissolve
Start the PVA removal process with the touch of a button. Let the PVA dissolve. typically within 1-8 hours2. while you get on with your day
Remove and Repeat
Raise the basket and remove your print. Water can be safely disposed of down the drain3. then refilled ready for the next print
Remove and Repeat
Raise the basket and remove your print. Water can be safely disposed of down the drain3. then refilled ready for the next print
Using the PVA Removal Station in 3 easy steps
Post-processing made simpler
Technical specifications
| Container volume | 13.7 liters (3.6 US gal) |
| Maximum part size | 200 x 230 x 165 mm (7.8 x 9 x 6.4 in) |
| Supported materials | Optimized for: PLA and PVA Also suitable for: PETG. Tough PLA. Nylon. or CPE in combination with PVA (Also supports equivalent third-party materials) |
| Supported solvents | Water |
| Rotor speed | 225 RPM (normal) 100 RPM (low) |
| Operating sound | < 50 dBA |
| Dimensions | 303 x 325 x 374 mm (11.9 x 12.8 x 14.7 in) |
| Dimensions with handle extended | 303 x 325 x 528 mm (11.9 x 12.8 x 20.8 in) |
| Net weight | 6.35 kg (14 lbs) |
| Container weight (empty) | 4.2 kg (9.3 lbs) |
| Shipping box dimensions | 400 x 400 x 500 mm (15.7 x 15.7 x 19.7 in) |
| Shipping weight | 8.5 kg (18.7 lbs) |
| Operating ambient temperature | 15 – 32 C (59 – 90 F) |
| Non-operating temperature | 0 – 32 C (32 – 90 F) |
| Relative humidity | 10 – 90% RH non-condensing |
| Voltage | 100 – 240 V AC |
| Frequency | 50 – 60 Hz |
| Power | 38 W |
| Warranty period | 12 months |
| Expert support | Market-leading technical support via email. phone. or from our global community is available to you in your language and timezone. |
| Extended support | Online resources. extensive manuals. material technical and safety data sheets (in multiple languages). a detailed knowledge base. and much more. |
